Brand: Turan BorfitElbow 45° (KIT Injection Welded) (SDR17) · PE100 SDR17 10bar (su) / 6bar (gaz)
Home/Products/Spigot Fittings/Elbow 45° (KIT Injection Welded)/Elbow 45° (KIT Injection Welded) (SDR17) · PE100 SDR17 10bar (su) / 6bar (gaz)
Spigot Fittings
Elbow 45° (KIT Injection Welded)
WATER: 10 bar · GAS: 6 bar
Selected: 355 · 20201100355-000
| d | Base Norm | D2 | L | h1 | Z | R | Unit Weight (kg) | Item Code |
|---|---|---|---|---|---|---|---|---|
| 355 | KIT | 21.66 | 145.00 | 4.97 | 230.00 | 2.84 | 10.78 | 20201100355-000 |
| 400 | KIT | 24.41 | 145.00 | 5.60 | 253.00 | 3.20 | 15.21 | 20201100400-000 |
| 450 | KIT | 27.46 | 170.00 | 6.30 | 310.00 | 3.60 | 23.06 | 20201100450-000 |
| 500 | KIT | 30.51 | 185.00 | 7.00 | 335.00 | 4.00 | 31.08 | 20201100500-000 |
| 560 | KIT | 34.17 | 100.00 | 7.84 | 265.00 | 4.48 | 31.74 | 20201100560-000 |
| 630 | KIT | 38.44 | 100.00 | 8.82 | 280.00 | 5.04 | 42.24 | 20201100630-000 |
All dimensions are indicative. Refer to the catalogue for full data.
